Quick Details

  • Condition: New
  • Type: Wood shaving machine
  • Use: Woodworking
  • Style: Horizontal
  • Place of Origin: Shandong, China (Mainland)
  • Brand Name: Sawmill-world
  • Model Number: SHBH500-1 SHBH500-2 SHBH500-4 SHBH500-6
  • Usage: Cutting Wood
  • Voltage: 380V
  • Power(W): 7.5KW-30KW
  • Dimension(L*W*H): 3250*3150*900mm
  • Weight: 2000kg
  • Certification: ISO CE SGS
  • Warranty: 1 Year
  • After-sales Service Provided: No overseas service provided
  • Color: Customer Actual Requirements
  • Keyword: Wood Cutting Machine
  • The shortest length of processing: 600mm
  • Saw Blade Quantity: 4-48
  • Feeding Motor: 1.5kw-2.2kw
  • Name: Wood shaving making machine
  • Cutter shaft: 1-6
  • Wood width(mm: 500
  • Wood length(mm): 800-1600
  • Depth of wood shaving (mm): 0.2-2

Packaging & Delivery

Packaging Details Iron frame packaging or according to Your need. for Making wood shaving,wood shaving making machine,small wood shaving machine with CE certification
Delivery Time 20 days after order confirmation

Making wood shaving,wood shaving making machine,small wood shaving machine with CE certification

also called Wood Paring Machine, or Wood Flaker (Machine), which can making the wood log into wood shaving. The wood shaving can be used to the animal bedding





Product Description





Wood shavings should not be confused with wood chips, since they are manufactured by an entirely

different process. Our machines cut the wood lengthwise, with the grain of the wood, to obtain thin, curly,

fluffy shavings rather than the hard, chunky texture of chips. A wide range of product characteristics can be obtained with different machine settings, with corresponding variations in production rates.



Main feature:



                        •The machine can be logs, branches (branches), edge processing into shavings, produced shavings and furniture factory to produce the shavings, automatic feeding equipment, greatly improving the production speed, it also saves time and manpower.

                  •This machine is a automatic grinding processing equipment of wood into wood shavings, after raw material from the inlet to the first blade, cutting into the crushing chamber, the high speed rotating hammer impact and shear knife under the employment of pieces, and then the wind generated by the built-in blades by the screen sent out of the mouth or the outer fan pumping out of the mouth.Particle size by adjusting the blade length and mesh size to determine the size, to meet different needs.



DETAILS DISPLAY




Wood shaving machine(Diesel Engine)

Model

SHBH500-2

SHBH500-4

SHBH500-6

Wood length(mm)

800

16001600

Wood width(mm)

500

500

500

Cutter shaft

246

Blades(pieces)

81624

Speed (r/min)

3500

3500

3500

Length of hopper (mm)

800

16001600

Diesel Engine(hp)

20hp

30hp

40hp

Depth of wood shaving (mm)

0.2-2

0.2-2

0.2-2

Capacity

500KG/hour

1000KG/hour

1500KG/hour





Wood shaving machine(Electric Motor)

Model

SHBH500-1

SHBH500-2

SHBH500-4

SHBH500-6

Wood length(mm)

800

800

16001600

Wood width(mm)

500

500

500

500

Cutter shaft

1246

Blades(pieces)

481624

Speed (r/min)

3500

3500

3500

3500

Length of hopper (mm)

800

800

16001600

Main power (kw)

7.7KW

10.5KW

21.25KW

28.75KW

Depth of wood shaving (mm)

0.2-2

0.2-2

0.2-2

0.2-2

Capacity

250KG/hour

500KG/hour

1000KG/hour

1500KG/hour



Packaging & Shipping








Loading PortQingdao or according to the customer demand
PackageIron Shelf or Wooden Box
Delivery Date10-20 workdays after receiving deposits
 PaymentTT: 30% deposits, balance before shipment

Our Services



Pre-Sales Service.

*Inquir and consulting support.
*According to customer's use and requirements for the customer design the best processes and programs
*View our Factory.

After-Sales Service.

* Mechanical equipment unified warranty 1 year, provided free of charge within one year machinery spare parts
* Engineers available to service machinery
overseas.Training how to instal the machine, training how to use the machine.

FAQ.

1) How can I place order?
A: You can contact us by email about your order details.
2) How can I pay you?
A: After you confirm our PI, we will request you to pay. T/T (HSBC bank) or Western Union,
there are the most usual ways we are using.
3)How do you take care when your clients received defective products?
A: Almost never happen,Before shipment, we will be
commissioning for many times,and will be sent to the customer inspection.
4)How about your after-sales Service?
A: Within a year, we will provide free spare parts, but need to customers pay the freight.

5) What's the order procedure?
A: First we discuss order details, production details by email or TM.
Then we issue you an PI for your confirmation.
You will be requested to do pr -epaid full payment or deposit before we go into production.
After we get the deposit, we start to process the order. We usually need 10-
20days if we don't have the items in stock. Before production has been finished,
we will contact you for shipment details, and the balance payment.
After payment has been settled, we start to prepare the shipment for you.
